Description

There are mainly PC modification, ABS modification, PBT modification, etc., as well as PC alloy series, including PC/ABS alloy, PC/PBT alloy, PC/PET alloy. Modified PC series include (flame retardant, reinforced, anti-aging, antistatic, wear-resistant, etc.) and modified ABS include (flame retardant, heat resistant, high impact, high gloss, etc.) material, PC shading material, PC paint-free, etc.), and has won unanimous praise from customers. The PC flame retardant materials we produce are matched with many well-known domestic enterprises, such as: Bull Group, Delixi Group, Hongyan Electric, Chint Group, Sunshine Group, Ruiming Electric, Haitian Technology, etc., and have long-term cooperation.

In addition, the company's products have been sold all over the world. Our customers come from more than 20 countries such as South Korea, Russia, Bangladesh, Vietnam, Kazakhstan, India, Indonesia, Ghana, Nigeria, South Africa, Egypt, and Saudi Arabia.

Basic Info.

Model NO.	FLX-1030GF	Flame Retardant Class	V0 V1 V2 Hb
Impact Strength	High Impact	Mfr	5-10
Long/Short Glass Fiber	Long Glass Fiber	Factory or Trade Company	Modified Plastic Factory
Colors	Black	Delivery	5 Days
Sample	Free	Process	njection Molding
Application	Auto Parts	Transport Package	Environmental Protection Woven Bag
Specification	25kg/Bag	Trademark	FLXSH
Origin	China	HS Code	3902100090
Production Capacity	20000tons/Year

Product Description

Reinforcing a thermoplastic with long glass fiber is a cost-effective way to boost mechanical properties of unreinforced resin systems and, even, short fiber solutions. It offers a noticeable improvement in stiffness and strength properties, but, more impressively, in impact strength. During processing these longer fibers intertwine and align to form an internal fiber skeleton that strengthens the polymer to help carry and dissipate stress forces - greatly increasing strength and impact resistance. This toughness is retained in demanding environments, such as cold temperatures (-60°F/-51°C).

Long glass fiber composites start as continuous filaments of fiber, which we melt-impregnate with thermoplastic polymer in our pultrusion process to create a high performance bond. These unidirectional fiber-reinforced strands are then cut into 1/2 inch (12 mm) composite pellets for convenient processing into net shapes via injection molding. Higher aspect ratio fiber reinforcement through the full length of our pellets results in more robust properties than short/chopped glass fiber filled compounds. This also includes a significant jump in cyclical fatigue endurance and creep.

Long glass fiber is a strong yet ductile fiber reinforcement solution that is commonly used in metal replacement applications due to the high strength properties, lower specific gravity and attractiveness of the injection molding processing method. In conjunction with the advantages of organic design possibilities from the injection molding forming process, it is common to see a 40-50% weight reduction in applications when switching from metal incumbents (aluminum, magnesium). Part consolidation is also an area of benefit as well - eliminating the weight of fasteners and minimizing the risk of secondary assembly steps.

Our long glass fiber reinforced products range from 20-50% fiber content (by weight) across a variety of resin systems ranging from polypropylene to higher performance engineering polymers such as PA. Additive technologies such as custom color, lubrication and UV performance enhancement are also available to customize your solution.

Item		PP				Model:FLX-1030GF
Product characteristics		Long Glass Fiber GF30%		Method of processing : Injection molding
Test Environment:Constant temperature and humidity
NO.	Proofing Courses	Test Conditions	Test Standards		Units		Test Results
1	Melt Index	260ºC,5kg	ASTM D-1238		g/10min		5
2	Density	/	ASTM D-792		g/cm3		1.31
3	Mold Shrinkage	150×100×3.2mm	ASTM D-955		%		1.2-1.4
4	Tensile Strength	50mm/min	ASTM-D-638		Mpa		38
5	Breaking Elongation	50mm/min	ASTM-D-638		%		9
6	Flexural Strength	2mm/min	ASTM-D-790		Mpa		55
7	Flexural Modulus	2mm/min	ASTM-D-790		Mpa		5019
8	IZOD Impact strengthnotched	23ºC,3.2mm	ASTM-D-256		J/M		46
9	HDT	0.45MPA	ASTM-648		ºC		142.5
10	Glass fiber content	800ºC/2H	/		%		30
11	Ball pressure	125°/1H	IEC60695-10-2		mm		1.2mm
12	Flammability	1.5mm	UL-94		Class		HB

Application field:

1 Auto Parts
Front end modules, door modules, shift mechanisms, electronic accelerator pedals, dashboard frames, cooling fans and frames, battery brackets, bumper brackets, underbody protection panels, sunroof frames, etc. are used to replace reinforced PA or metal materials.

2 Home Appliance Industry
Washing machine roller, washing machine triangle bracket, a brush machine roller, air conditioning fan, etc., used to replace short glass fiber reinforced PA, APS metal materials.

3 Communication, electronics, electrical industry
High-precision connectors, igniter components, coil shaft, relay base, microwave oven transformer coil frame/frame, electrical connectors, solenoid valve packages, scanner components, etc.

4 Other Areas
Power tool shell, water pump or water meter shell, impeller, bicycle skeleton, skis, ground locomotive pedal, safety helmet, safety shoe head, etc., used to replace short glass fiber reinforced PA, PPO, etc
