Reinforced GF 20% 30% Flame Retardant UL V0 High Impact PBT for Auto Parts
Item No.：
C-001
Item No.：
FLX-PBT 20
Category：
Summary
Ningbo Sailing Farai New Material Co., LTD. was founded in 1998. It is a company specializing in the research, development, production and sales of engineering plastics, general-purpose plastics and modified plastics.
Description
There are mainly PC modification, ABS modification, PBT modification, etc., as well as PC alloy series, including PC/ABS alloy, PC/PBT alloy, PC/PET alloy. Modified PC series include (flame retardant, reinforced, anti-aging, antistatic, wear-resistant, etc.) and modified ABS include (flame retardant, heat resistant, high impact, high gloss, etc.) material, PC shading material, PC paint-free, etc.), and has won unanimous praise from customers. The PC flame retardant materials we produce are matched with many well-known domestic enterprises, such as: Bull Group, Delixi Group, Hongyan Electric, Chint Group, Sunshine Group, Ruiming Electric, Haitian Technology, etc., and have long-term cooperation.
In addition, the company's products have been sold all over the world. Our customers come from more than 20 countries such as South Korea, Russia, Bangladesh, Vietnam, Kazakhstan, India, Indonesia, Ghana, Nigeria, South Africa, Egypt, and Saudi Arabia.
Basic Info.
| Model NO | FLX-PBT 20 | Process | Injection Molding |
| Customize | Yes | Flammability | Fr UL VO |
| Reinforced | GF10% 20% 30% | Sample | 10 kg Is Free |
| Delivery | 3-7 Days | Transport Package | Environmental Protection Woven Bag |
| Specification | 25kg/Bag | Trademark | FLXSH |
| Origin | China | HS Code | 3907991090 |
| Production Capacity | 20000tons/Year | ||
Packaging & Delivery
|
Package Size |
75.00cm * 45.00cm * 12.00cm |
|
Package Gross Weight |
25.000kg |
Product Description
PBT Reinforced 20%30% 40% UL V0
Good liquidity, easy to form
Resistance to stress cracking
Can spray oil, can be electroplated
Resistant to chemical agents such as glacial acetic acid
Ultra-high impact strength
Excellent fatigue resistance
Excellent dimensional accuracy and stability
No toxicity
Wide temperature range: from low temperature -40ºC to 180ºC
Good electrical performance and flame retardant
High whiteness, high temperature resistance
Flame retardant without halogen
Excellent shading and reflection effect
Excellent UV resistance
 |
 |
WHAT IS PBT RESIN?
PBT (polybutylene terephthalate) is a semi-crystalline engineering thermoplastic material that offers very good chemical resistance with high levels of mechanical and thermal properties. PBT material has good dimensional stability and is unaffected by ambient humidity. This semi-crystalline thermoplastic also has low friction and resistance to abrasion. The addition of additives can further enhance pbt material properties
The rigidity of Polybutylene terephthalate can be increased by the addition of glass fibers in a loading range of 10% to 40%. Flame retardants can be added to TP to provide performance profiles required for electrical/electronics applications. Although TP is not as ductile as other materials, such as polycarbonate, impact modifiers can be added to provide high impact products. Additives can also be combined to give the products broad property profiles. Examples of this include flame retardant glass filled TP, and flame retardant impact-modified Polybutylene terephthalate.
The semi-crystalline nature of PBT material causes it to have both higher shrinkage values and higher specific gravity values than amorphous thermoplastics. These factors should be taken into account when designing parts.
Additives, Modifiers, and Reinforcing Agents:
Additives - UV stability, easy release (mold releases), colorants, and other stability additives
Modifiers - Flame retardants, impact modifiers, flow enhancers
Reinforcing Agents - Glass fibers, mineral fillers
| Item | PBT | Model | |||||
| Product characteristics | enhancement 20% 30% ,flame retardant | Method of processing : Injection molding | |||||
| Test Environment:Constant temperature and humidity | |||||||
| NO. | Proofing Courses | Test Conditions | Test Standards | Units | Test Results | ||
| 1 | Melt Index | 300ºC,1.2kg | ASTM D-1238 | g/10min | 30 | ||
| 2 | Density | / | ASTM D-792 | g/cm3 | 1.55 | ||
| 3 | Mold Shrinkage | 150×100×3.2mm | ASTM D-955 | % | 0.4-0.6 | ||
| 4 | Tensile Strength | 50mm/min | ASTM-D-638 | Mpa | 110 | ||
| 5 | Breaking Elongation | 50mm/min | ASTM-D-638 | % | 4 | ||
| 6 | Flexural Strength | 2mm/min | ASTM-D-790 | Mpa | 150 | ||
| 7 | Flexural Modulus | 2mm/min | ASTM-D-790 | Mpa | 5900 | ||
| 8 | IZOD Impact strengthnotched | 23ºC,3.2mm | ASTM-D-256 | J/M | 75 | ||
| 9 | HDT | @1.82MPA | ASTM-648 | ºC | 195 | ||
| 10 | Glow Wire Tester | 850ºC |
GB/5169 |
S | ≤30S | ||
| 11 | Ball pressure | 125ºC | GB/T5169-21 | S | ≤2.0mm | ||
| 12 | Flammability | 1.6mm | UL-94 | Class | V 0 | ||
